Hydraulic Lever Clamps

Hydraulic lever clamps – double acting and single acting types:
Hydraulic lever clamps can be used wherever the clamping fixture needs to be freely loaded and unloaded when the clamping lever is swung back. Due to their compact design, they are particularly suitable for clamping applications where installation space is limited. Hydraulic lever clamps offer an economical solution for hydraulically clamping workpieces. Thanks to their short clamping lever, they generally provide higher clamping forces than swing clamps.

Hydraulic Lever Clamps – available series

HLKA

10 - 70 bar
double acting

HLKP

10 - 70 bar
double acting

HLCT

25 - 70 bar
single acting

HLS

Low pressure series up to 70 bar
Clamping force 2.90 kN to 11.36 kN

HLCF

20 - 70 bar
double acting

HLC

10 - 70 bar
2.52 kN to 14.82 kN

HBLU

10 - 70 bar
double acting

H12

5 - 70 bar
double acting
