DST-40344-R Latch type toggle clamp with vertical, with safety lock
Vertical Latch type toggle Clamp with locking mechanism :
- Pull action latch clamp
- Horizontal mounting base, vertical U-hook
- with safety lock to prevent the inadvertent or vibration-induced release of the clamp.
- Holding capacity : 9000N
- supplied with U-hook and latch plate
- Easy adjustable U-hook (within its range)
- Optional U-hook lengths available
- Weight : 660g
Note :
- Material: galvanic, zinc-plated high quality steel
- available in stainless steel without safety lock (DST-40344-SS)
- Hand grips designed for high user comfort
- e.g. suitable for 344-R, etc...
DST-40344-R Technical Drawing / Dimensions in [mm]
GH-40344-R Technical Drawing / Dimensions in [mm]
