DST-12145 Vertical acting toggle clamp 2270N

DST-12145 Vertical acting Hold-Down Toggle Clamp with horizontal vertical base solid Bar 2270N

Vertical acting toggle clamp with vertical base and solid bar:

• Straight Handle
• Adjustable solid bar, standard length
• Bar Opens : 100°
• Handle Opens : 60°
• with clamping screw, washer and nut element
• Spindle supplied : DST-FC-56212
• Holding Capacity : 2270N
• Weight : 340g
• Material: galvanic, zinc-plated high quality steel
• Hand grips designed for high user comfort

Note :

• e.g. suitable for 207-SB, etc.
• CAD-files and prices on Request !

Technical Specifications
Item-Number	DST-12145
Material	galvanized steel
Max. holding force (N)	2270
Height under clamping arm (mm)	46.9
Overall height (mm)	159
Total length (mm)	58.5
Clamping arm length (mm)	103
Clamping arm opening angle °	100
Handle opening angle °	60
Safety interlock	Nein
Clamping screw	FC-56212
Base alignment	straight base
Version	Normal
Weight (g)	340
Order number	DST-12145
Series	DST
Price from	on request

Show all technical data

Technical Drawing and Dimensions in [mm]
