Horizontal acting toggle clamps 270N

Horizontal toggle clamps – miniature and low-profile design:

Horizontal quick-action clamps in this series are the smallest in our range and are specifically designed for light loads and confined spaces, particularly due to their exceptionally low overall height.

ul>
  • Enhanced Stability: Reliable clamping for medium loads with a holding force of up to 900N.
  • Low-Profile Design: Maintains maximum accessibility to the workpiece due to the horizontal handle position.
  • Industrial Durability: High-quality galvanized steel or stainless steel (NI) versions ensure longevity in demanding environments.
  • Flexible Mounting: Available with horizontal, vertical, or angled bases to fit any fixture requirement.

DST-201

DST-201 Horizontal acting toggle clamp with horizontal mounting base 270N
Holding force
270
Height
17.3
horizontal mounting base
Horizontal acting toggle clamp

DST-201-SS

Horizontal acting toggle clamp with horizontal mounting base270N - STAINLESS STEEL
Holding force
270
Height
17.3
stainless steeless
Horizontal acting toggle clamps

DST-201-A

DST-201-A Horizontal acting toggle clamp with horizontal mounting base 270N
Holding force
270
Height
17.3
mini type | solid bar
Horizontal acting toggle clamps

DST-201-ASS

DST-201-ASS Horizontal acting toggle clamp with horizontal mounting base270N - STAINLESS STEEL
Holding force
270
Height
17.3
stainless steel
Horizontal acting toggle clamps

DST-201-AI

DST-201-AI Horizontal acting toggle clamp with vertical mounting base 270N
Holding force
270
Height
25.3
vertical base | solid bar
Horizontal acting toggle clamps

DST-201-AL

DST-201-AL Horizontal acting toggle clamp with left flanged base 270N
Holding force
270
Height
17.3
left flanged base
Horizontal acting toggle clamps

DST-201-AR

DST-201-AR Horizontal acting toggle clamp with right flanged base 270N
Holding force
270
Height
17.3
right flanged base
Horizontal acting toggle clamps

DST-201-I

DST-201-I Horizontal acting toggle clamp with vertical mounting base 270N
Holding force
270
Height
25.3
vertical base | solid bar
Horizontal acting toggle clamps

DST-201-L

DST-201-L Horizontal acting toggle clamp with left flanged base 270N
Holding force
270
Height
17.3
left flanged base
Horizontal acting toggle clamps

DST-201-R

DST-201-R Horizontal acting toggle clamp with right flanged base 270N
Holding force
270
Height
17.3
right flanged base
Horizontal acting toggle clamps

Technical Product Overview: Horizontal acting toggle clamps 270N

Model No. Material Base Holding Capacity
(kN)		 Height
(mm)		 Length
(mm)		 Clamping Arm
(mm)		 Arm
Angle		 Handle
Angle		 Weight
(g)		 Details
DST-201 Steel Horizontal 270 17.3 78.5 12.5 90° 80° 35 Details
DST-201-SS Stainless Steel Horizontal 270 17.3 78.5 12.5 90° 80° 35 Details
DST-201-A Steel Horizontal 270 17.3 81 17.8 90° 80° 30 Details
DST-201-ASS Stainless Steel Horizontal 270 17.3 81 17.8 90° 80° 30 Details
DST-201-AI Steel Vertical 270 25.3 81 22.5 90° 80° 30 Details
DST-201-AL Steel Horizontal 270 17.3 81 -17.8 90° 80° 30 Details
DST-201-AR Steel Horizontal 270 17.3 81 17.8 90° 80° 30 Details
DST-201-I Steel Vertical 270 25.3 78.5 20 90° 80° 35 Details
DST-201-L Steel Horizontal 270 17.3 78.5 20 80° 90° 30 Details
DST-201-R Steel Horizontal 270 17.3 78.5 20 80° 90° 30 Details
